ROYALOHM Datasheet:
CRT03J7E0470.pdf
Description:
Manufacturer VIKING Resistors RES.(1608) 0603 47 Ohms 5% 1/10W-S 100PPM
Features:
Halogen Free Epoxy
RoHS compliant
Products with lead free terminations meet RoHS requirements
Pb-glass contained in electrodes, resistors element and glassare exempted by RoHS
Reducing environmentally hazardous wastes
High component and equipment reliability saving of PCB space
None forbidden-materials used in products/production
Applications:
All general purpose application
CRT Series
| Type | Power Rating at 70℃ | Operating Temp.Range | Max. Operating Voltage | Max. Overload Voltage | Dielectric Withstanding Voltage | Resistance Range | TCR (PPM/℃) | |
| ±0.1% (E24、E96) | ±0.5% (E24、E96) | |||||||
| CRTE5(01005) | 1/32W | -55～+125℃ | 15V | 30V | 30V | 100≤R≤1000 | ±300 | |
| 100Ω | ±200 | |||||||
| CRT01 (0201) | 1/20W | -55～+125℃ | 25V | 50V | 50V | 10Ω | 10≤R≤100 | ±300 |
| 10Ω | ±200 | |||||||
| CRT02 (0402) | 1/16W | -55～+155℃ | 50V | 100V | 100V | 10Ω | 10≤R≤100 | ±200 |
| 10Ω | ±100 | |||||||
| CRT03 (0603) | 1/10W | -55～+155℃ | 75V | 150V | 150V | 10Ω | 10≤R≤10Ω | ±200 |
| 10Ω | ±100 | |||||||
| CRT05 (0805) | 1/8W | -55～+155℃ | 150V | 300V | 300V | 10Ω | 10≤R≤100 | ±200 |
| 10Ω | ±100 | |||||||
| CRT06 (1206) | 1/4W | -55～+155℃ | 200V | 400V | 500V | 10Ω | 10≤R≤100 | ±200 |
| 10Ω | ±100 | |||||||
| CRT10(1210) | 1/2W | -55～+155℃ | 200V | 500V | 500v | 10Ω | ±200 | |
| 10Ω | ±100 | |||||||
| CRT0A(2010) | 3/4W | -55～+155℃ | 200V | 500V | 500V | 10Ω | ±200 | |
| 10Ω | ±100 | |||||||
| CRT12(2512) | 1W | -55～+155℃ | 200V | 500V | 500V | 10Ω | ±200 | |
| 10Ω | ±100 | |||||||
