FEATURES
Single-channel, 1024-/256-position resolution
20 kΩ, 50 kΩ, 100 kΩ nominal resistance
Maximum ±1% nominal resistor tolerance error
50-times programmable (50-TP) wiper memory
Rheostat mode temperature coefficient: 5 ppm/°C
2.7 V to 5.5 V single-supply operation
±2.5 V to ±2.75 V dual-supply operation for ac or bipolar
operations
I
2C-compatible interface
Wiper setting readback
Power on refreshed from 50-TP memory
Thin LFCSP 10-lead, 3 mm × 3 mm × 0.8 mm package
Compact MSOP, 10-lead 3 mm × 4.9 mm × 1.1 mm package
Commodity attributes：
Brand:
ADI
Package:
MSOP10
batch:
21+
quantity:
2500
manufacturer:
Analog Devices Inc.
Cone:
linear
Configuration:
rheostat
Number of circuits:
1
Number of taps:
1024
Resistance (ohms):
20k
interface:
I²C
Storage type:
non-volatile
Voltage - Power Supply:
2.7V ~ 5.5V, ±2.5V ~ 2.75V
characteristic:
optional address
Tolerance:
±1%
Temperature Coefficient (Typical):
5ppm/°C
Installation type:
surface mount type
Package/Case:
10-TFSOP, 10-MSOP (0.118", 3.00mm width)
Operating temperature:
-40°C ~ 125°C
Available for sale:
the whole country
type:
Integrated Circuits (ICs) Data Acquisition - Digital Potentiometers
model:
AD5272BRMZ-20-RL7
